Short Description

The Lutron PMS-714 is a professional digital soil moisture meter designed to accurately measure the moisture content of soil and similar materials. Featuring a durable two-pin electrode probe, microprocessor-controlled circuitry, and a clear LCD display, it provides fast and reliable moisture readings from 0% to 50%. Ideal for agriculture, horticulture, landscaping, greenhouses, research laboratories, and environmental monitoring, the PMS-714 offers simple operation and dependable performance for both field and laboratory use.

Key Features

Professional Digital Soil Moisture Meter
Measures Soil Moisture Content from 0% to 50%
Precision Two-Pin Electrode Probe
High Accuracy Microprocessor Circuit
Large LCD Display
Fast Measurement Response
Data Hold Function
Low Battery Indicator
Compact & Lightweight Design
Durable ABS Plastic Housing
Easy One-Hand Operation
Suitable for Field & Laboratory Applications
Portable and Battery Powered

Applications

Ideal for:

Agriculture
Horticulture
Greenhouses
Plant Nurseries
Landscaping
Soil Testing Laboratories
Environmental Monitoring
Irrigation Management
Research Institutes
Universities
Gardening
Soil Science Studies

Technical Specifications

Soil Moisture Measurement

Parameter	Specification
Measuring Principle	Conductivity Measurement using Two-Pin Electrode
Measuring Range	0.0 to 50.0% Soil Moisture
Resolution	0.1%
Accuracy	±(5% Full Scale + 5 Digits)

Measurement Principle

Two stainless-steel electrode pins measure the conductivity of the soil.
The instrument converts conductivity into a direct soil moisture percentage reading.

Display

LCD Display
Display Size: 28 × 19 mm
Clear Digital Readout

Functions

Soil Moisture Measurement
Data Hold
Low Battery Indicator

Probe

Integrated Probe
Probe Length: 220 mm
Probe Diameter: 10 mm
Two Stainless Steel Electrodes

Sampling Time

Approximately 0.8 seconds

Operating Conditions

Operating Temperature

0°C to 50°C

Operating Humidity

Less than 80% RH

Power Supply

4 × 1.5V AAA Batteries (UM-4)

Power Consumption

Approximately 12 mA

Dimensions

Meter Body

172 × 40 × 40 mm

Probe

220 mm × 10 mm Diameter

Total Length

392 mm

Weight

Approximately 267 g (including batteries)

Construction

High-Impact ABS Plastic Housing
Corrosion-Resistant Metal Electrodes
Microprocessor-Based Electronics

Standard Package Includes

Lutron PMS-714 Soil Moisture Meter
User Instruction Manual

Optional Accessories

Hard Carrying Case (CA-06)

Advantages

Quick and Accurate Soil Moisture Measurement
Easy-to-Read Digital Display
Durable Probe Design
Lightweight and Portable
Reliable for Field and Laboratory Use
Low Maintenance
Rugged Construction
Simple One-Hand Operation
Long Battery Life
Ideal for Routine Soil Analysis

Industries Served

Agriculture
Horticulture
Greenhouse Farming
Landscaping
Environmental Monitoring
Research Laboratories
Educational Institutions
Irrigation Management
Forestry
Plant Science

SOIL MOISTURE METER
